DMC2038LVT-7 26-TSOT MOSFET N/P-CH 20V TSOT26

Brand: Diodes Inc

Product Code: #318942

Availability:In stock

$0.79 0.79

Qty

Ask about this product
DMC2038LVT-7 DescriptionDMC2038LVT-7 Datasheet
FET Type N and P-Channel
FET Feature Logic Level Gate
Drain to Source Voltage (Vdss) 20V
Current - Continuous Drain (Id) @ 25 C 3.7A 2.6A
Rds On (Max) @ Id Vgs 35 mOhm @ 4A 4.5V
Vgs(th) (Max) @ Id 1V @ 250?A
Gate Charge (Qg) @ Vgs 17nC @ 10V
Input Capacitance (Ciss) @ Vds 530pF @ 10V
Power - Max 770mW
Mounting Type Surface Mount
Supplier Device Package 26-TSOT
