2N7002K-7 SOT-23-3 MOSFET N-CH 60V 300MA SOT23-3

Brand: Diodes Inc

Product Code: #438263

Availability:In stock

$0.43 0.43

Qty

Ask about this product
2N7002K-7 Description2N7002K-7 Datasheet
FET Type MOSFET N-Channel Metal Oxide
FET Feature Logic Level Gate
Drain to Source Voltage (Vdss) 60V
Current - Continuous Drain (Id) @ 25 C 380mA
Rds On (Max) @ Id Vgs 2 Ohm @ 500mA 10V
Vgs(th) (Max) @ Id 2.5V @ 1mA
Gate Charge (Qg) @ Vgs 0.3nC @ 4.5V
Input Capacitance (Ciss) @ Vds 50pF @ 25V
Power - Max 370mW
Mounting Type Surface Mount
Supplier Device Package SOT-23-3
